| ENGINE
+
|
| Engine | 1000 |
| Engine displacement | 1000 |
| Type | 80 hp ( 59 kW), Rotax 976 cc V-twin, liquid cooled |
| Fuel Delivery System | Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI) |
| Transmission | CVT, P / R / N / H / Extra Low L, standard engine braking |
| Drive Train | Selectable 2WD / 4WD with Visco-Lok+ QE auto-locking front differential |
| Power Steering | Tri-Mode Dynamic Power Steering (DPS) |
| SUSPENSION
+
|
| Front Shocks | Oil |
| Rear Suspension | Torsional Trailing arm Independent (TTI) 9.9 in. (25,1 cm) travel |
| Rear Shocks | Oil |
| Front Suspension | Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel |
| TIRES/WHEELS
+
|
| Rear Tires | Carlisle† ACT HD 26 x 10 x 12-in. (66 x 25.4 x 30.5 cm) |
| Wheels | 12 in. cast-aluminum |
| Front Tires | Carlisle† ACT HD 26 x 8 x 12-in. (66 x 20.3 x 30.5 cm) |
| BRAKES
+
|
| Rear | Single 214 mm ventilated disc brake with hydraulic twin-piston caliper |
| Front | Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers |
| DIMENSIONS / CAPACITIES
+
|
| L x W x H | 238.8 x 122 x 135 cm |
| Wheel Base | 59 in. (149.9 cm) |
| Ground Clearance | 30.5 cm |
| Dry Weight | 375 kg |
| Rack Capacity | Front: 100 lb (45 kg) / Rear: 200 lb (90 kg) |
| Storage Capacity | Rear: 5.7 gal (21.4 L) |
| Towing Capacity | 750 kg trailer with brakes 395 kg trailer without brakes |
| Fuel Capacity | 5.4 gal (20.5 L) |
| Seat Height | 34.5 in. (87.7 cm) |
| FEATURES
+
|
| Instrumentation | Lighter type DC outlet in console, standard connector in the back (15-A) |
| Anti Theft System | Digitally Encoded Security System (D.E.S.S.™) |
| Lighting | 230 W from twin 60-W projectors and dual 55-W reflectors with tail light / brake light |
| Winch | 1,361 kg (3,000 lbs) WARN winch with roller fairlead |
| Seat | Convertible Rack System (CRS) with reinforced seat skin |
| Protection | Heated hand grips, mudguards |
| Gauge | 4.5 in. digital display : Speedometer, tachometer, odometer, trip & hour meters,gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge & clock |
| WARRANTY
+
|
| Factory | 2 years BRP limited warranty |
