| ENGINE
+
|
| Engine | HD10 |
| Engine Displacement | 976 |
| Type | HD10: 82 hp ( 61 kW), Rotax® 976 cc, V-twin, liquid cooled |
| Fuel Delivery System | Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI) |
| Transmission | PRO-TORQ transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Extra-L / H / N / R / P |
| Drive Train | Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential |
| Driving Assistance | Electronic Hill Descent Control ECO / ECO Off / Work modes |
| Power Steering | Dynamic Power Steering (DPS) |
| SUSPENSIONS
+
|
| Front Suspension | Arched double A-arm / 11 in. (27.9 cm) travel |
| Front Shocks | Twin tube gas charged shocks |
| Rear Suspension | Arched TTA with external sway bar / 11 in. (27.9 cm) travel |
| Rear Shocks | Twin tube gas charged shocks |
| TIRES / WHEELS
+
|
| Front Tires | Maxxis Bighorn 2.0 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm) |
| Rear Tires | Maxxis Bighorn 2.0 27 x 11 x 14 in. (68.6 x 27.9 x 35.6 cm) |
| Wheels | 14-in. cast-aluminum |
| BRAKES
+
|
| Front | Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
|
| Rear | Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers |
| DIMENSIONS
+
|
| L x W x H | 154.1 x 64 x 78 (391.5 x 162.5 x 198.1 cm) |
| Wheelbase | 115.5 in. (294 cm) |
| Ground Clearance | 13 in. (33 cm) |
| Estimated Dry Weight | 1833 lb (831.5 kg) |
| Cage | ROPS-approved profiled cage.
Certified ISO 3471 and OSHA. |
| Cargo Box Dimensions | 72 x 54.5 x 10 in. (180,3 x 138.4 x 25.4 cm) |
| Cargo Box Capacity | 1,000 lb (454 kg) |
| Tailgate Load Capacity | 250 lb (113.4 kg) |
| Storage Capacity | Total: 94 gal (356 L) Under dash: 6 gal (22.8 L) Dash: 1.8 gal (6.9 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 0.9 gal (3.5 L) 83.6 gal (316.5 L) Lower box storage 83.6 gal (316.5 L) |
| Towing Capacity | 1134 kg |
| Payload Capacity | 1700 lb (771 kg) |
| Fuel Capacity | 40 L
|
| Person Capacity | 3 |
| FEATURES
+
|
| Gauge | 4.5 in. wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature |
| Battery | 12 V (30 amp/h) |
| Magneto | 650 W |
| Instrumentation | Two lighter type DC outlets, one in the console
(20-A) and one in the under dash storage (20-A) |
| Lighting | 140 W lighting output from four 35-W reflectors ensuring a wide visibility and LED tail lights
|
| Winch | N/A |
| Seat | VERSA-PRO bench seat with passenger seats flipping up, adjustable driver seat, underside
hooks, reinforced XT seat skin and contoured bench to improve entrance/exit of the cab |
| Protection | XT front bumper, full HMW skid plate, full hard roof |
| Hitch Type | 2-in. hitch receiver |
| Steering Wheel | Adjustable tilt steering |
| WARRANTY
+
|
| Factory | 2 years BRP limited warranty |
