| ENGINE
+
|
| Engine | HD10 |
| Engine Displacement | 976 |
| Type | HD10: 82 hp ( 61 kW), Rotax 976 cc, V-twin, liquid cooled |
| Transmission | PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P |
| Fuel Delivery System | Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
|
| Drive Train | Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential Open front Differential with ABS system |
| Driving Assistance | Electronic Hill Descent Control. ECO / ECO Off / Work modes |
| Power Steering | Dynamic Power Steering (DPS) |
| Speed category | Up to 60 km/h |
| SUSPENSIONS
+
|
| Rear Shocks | Twin tube gas charged shocks |
| Front Suspension | Double A-arm
27.9 cm travel |
| Front Shocks | Twin tube gas charged shocks |
| Rear Suspension | Arched TTA with external sway bar
27.9 cm travel |
| TIRES / WHEELS
+
|
| Front Tires | Maxxis Coronado 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm) |
| Rear Tires | Maxxis Coronado 27 x 11 x 14 in. (68.6 x 27.9 x 35.6 cm) |
| Wheels | 14 in. cast-aluminum |
| BRAKES
+
|
| Front | Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear | Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers |
| Technology | Brake holding mechanism |
| DIMENSIONS
+
|
| L x W x H | 125.7 x 64 x 80 in. (319,4 x 162.5 x 203.2cm) |
| Wheelbase | 211.5 cm |
| Ground Clearance | 33 cm |
| Estimated Dry Weight | 1,594 lb (723 kg) |
| Cage | ROPS-approved profiled cage.
Certified ISO 3471 and OSHA. |
| Cargo Box Dimensions | 96.5 x 138.4 x 30.5 cm |
| Cargo Box Capacity | 454 kg |
| Tailgate Load Capacity | 113.4 kg |
| Storage Capacity* | Total: 62.3 L
Under dash: 22.8 L
Waterproof and removable box under
passenger seat: 21 L
Dash: 15 L
Armrests and cup holders: 3.5 L |
| Towing Capacity | 1134 kg |
| Payload Capacity | 680 kg |
| Fuel Capacity | 40 L |
| Person Capacity | 3 |
| FEATURES
+
|
| Magneto | 650W |
| Instrumentation | Two lighter type DC outlets, one in the console
(20-A) and one in the under dash storage (20-A) |
| Lighting | 140-W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights |
| Winch | 4,500-lb (2,014 kg) winch |
| Seat | VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab |
| Protection | Integrated front steel bumper HMWPE full skid plate |
| Hitch Type | 2-in. hitch receiver, 7-pin trailer connection (12V) |
| Steering Wheel | Adjustable tilt steering |
| Gauge | 7.6 in. wide digital display with keypad.
Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO/ECO Off/Work modes, seat belt indicator, diagnostics, clock, battery voltage, engine temperature |
| T-category features | Horn, flashers and position lamps, mirrors, hook on front metal bumper |
| Battery | 12 V (30 amp/h) |
| WARRANTY
+
|
| Factory | 2 years BRP limited warranty |
