| ENGINE
+
|
| Engine | ROTAX 600 ACE
|
| Engine displacement | 600 cc
900 cc |
| Type | Rotax® 600 ACE™ in-line 2 cylinders, liquid-cooled with electronic fuel injection and electronic throttle control
Rotax® 900 ACE™ in-line 3 cylinders, liquid-cooled with electronic fuel injection and electronic throttle control |
| Bore & stroke | 2.9 x 2.7 in. (74 x 69.7 mm) |
| Power | Ryker with 600 engine: 50 hp (37.3 kW) @ 7300 RPM
Ryker with 900 engine: 82 hp (61.1 kW) @ 8000 RPM |
| Torque | Ryker with 600 engine: 36.7 ft-lb (49.7 Nm) @ 6000 RPM
Ryker with 900 engine: 58.3 ft-lb (79.1 Nm) @ 6500 RPM |
| CO2 emissions | Ryker with 600 engine: 127 g/km
Ryker with 900 engine: 143 g/km |
| Fuel consumption | Ryker with 600 engine: 5.4 l/100 km (43.6 mpg)
Ryker with 900 engine: 6.08 l/100 km (38.7 mpg) |
| TRANSMISSION
+
|
| Transmission | Automatic (CVT) with reverse function |
| CHASSIS
+
|
| Front suspension | Double wishbone |
| Front shocks type / travel | SACHS† Twin-tube coil-over shocks / 5.35 in. (136 mm) |
| Rear suspension | Multi-link - mono swing arm |
| Rear shocks type / travel | SACHS† Twin-tube coil-over shocks with preload adjustment / 5.91 in. (150 mm) |
| Electronic brake distribution system | Foot-operated, hydraulic 3-wheel brake |
| Front brakes | 270 mm discs with Nissin 2-piston floating calipers |
| Rear brake | 220 mm disc, 1-piston floating caliper |
| Parking brake | Park lock |
| Front tires | MC 145/60R16 66T |
| Rear tire | MC 205/45R16 77T |
| Aluminum front rims | 5-spoke Carbon black, 16 x 4.5 in. (406 x 114 mm) |
| Aluminum rear rim | 5-spoke Carbon black, 16 x 6.5 in. (406 x 165 mm) |
| CAPACITY
+
|
| Rider capacity | 1 |
| Maximum vehicle load | 449.7 lb (204 kg) |
| Storage capacity | 1.85 gal (7 L) |
| Fuel capacity | 5.28 gal (20 L) |
| Fuel Type | Premium unleaded |
| DIMENSION
+
|
| L x W x H | Ryker with 600 engine: 2,352 x 1,522 x 1,063 mm (92.6 x 59.9 x 41.9 in.)
Ryker with 900 engine: 2,352 x 1,522 x 1,060 mm (92.6 x 59.9 x 41.7 in.) |
| Wheelbase | 67.3 in. (1,709 mm) |
| Seat height | Ryker with 600 engine: 23.6 in. (599 mm)
Ryker with 900 engine: 23.5 in. (597 mm) |
| Ground clearance | 97 mm (3.8 in.) |
| Dry weight | Ryker with 600 engine: 594 lb (270 kg)
Ryker with 900 engine: 616 lb (280 kg) |
| INSTRUMENTATION
+
|
| Type | 4.5" (11,4 cm) digital display |
| Main Functions | Ryker with 600 engine: Speedometer, tachometer, odometer, trips, distance to empty, engine lights, fuel gauge and clock
Ryker with 900 engine: Speedometer, tachometer, odometer, trips, distance to empty, engine lights, fuel gauge, clock, ECO mode and Sport mode |
| SAFETY AND SECURITY
+
|
| SCS | Stability Control System |
| TCS | Traction Control System |
| ABS | Anti-lock Braking System |
| Anti-theft system | Digitally Encoded Security System (D.E.S.S.™) |
| HHC | Hill Hold Control |
| COVERAGE
+
|
| Factory Warranty | 2-year BRP Limited Warranty |
| Roadside Assistance | 2-year roadside assistance provided by Allianz Assistance, world leader in Automotive and Travel assistance, on behalf of BRP. |
