| ENGINE
+
|
| Drive Train | Selectable 2WD / 4WD with lockable rear differential |
| Power Steering | Dynamic Power Steering (DPS) |
| Driving assistance | Brake and Traction Control System
SPORT / ECO™ modes |
| Speed category | More than 60 km/h |
| Type | 100 hp, Rotax® 976 cc, V-twin, liquid cooled |
| Fuel Delivery System | Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI) |
| Transmission | Quick Response System (QRS) CVT with high airflow ventilation and Electronic Drive Belt Protection
Extra-L / H / N / R / P |
| DIMENSIONS
+
|
| Length | 378.4 cm |
| Width | 152.4 cm |
| Height | 193.5 cm |
| Wheelbase | 306.3 cm |
| Ground Clearance | 30.5 cm |
| Dry Weight | 769.7 kg |
| Cage | ROPS-approved profiled cage. Certified ISO 3471. |
| Cargo Box Capacity | 136 kg |
| Storage Capacity | Total: 24.7 L
Glove Box: 15.6 L
Driver storage: 1.5 L
Center console and Cup holders: 3.1 L
Rear console and Cup holders: 4.5L |
| Towing Capacity | 680 kg |
| Fuel Capacity | 38 L |
| TIRES / WHEELS
+
|
| Front Tires | Maxxis Liberty
28 x 10 x 14 in. |
| Rear Tires | Maxxis Liberty
28 x 10 x 14 in. |
| Wheels | 14-in. cast-aluminum |
| SUSPENSIONS
+
|
| Rear Shocks | FOX† 2.0 PODIUM Piggyback with QS3† compression adjustment |
| Front Suspension | Double A-arm with sway bar / 32 cm travel |
| Front Shocks | FOX† 2.0 PODIUM Piggyback with QS3†compression adjustment |
| Rear Suspension | TTA with sway bar / 33 cm trave |
| BRAKES
+
|
| Front | Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
| Rear | Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers |
| ABS | Standard |
| FEATURES
+
|
| Gauge | 7.6” wide multifunction digital display |
| Instrumentation | Lighter type DC outlet in console (20-A) |
| Magneto | 650W |
| Lighting | Two 55 W reflectors with unique Can-Am LED signature and LED tail light |
| T-category features | Horn, flashers and position lamps, mirrors, hook on front metal bumper |
| Winch | Prewired for available winch |
| Steering Wheel | Adjustable tilt steering |
| Protection | Integrated front steel bumper, injected full body skid plates, mudguards, mudflaps, rear half doors and front net doors |
| Hitch Type | 2-in. hitch receiver with tow ball, 7-pin trailer connection (12V) |
| WARRANTY
+
|
| Factory | 2 years |
